Heliosa 66 Short Wave Infrared Heater

Heliosa 66 Short Wave Infrared Heater

$695.00 inc GST

The Helios 66 short-wave infrared heater offers the widest coverage of heat in the market.

  • Covers a heated area of up to 20 m² for one heater.
  • Instant heat within 1 second.
  • 92% of radiant efficiency.
  • Features a patented design of a parabolic reflector for maximum heat output.



Heliosa 66 heater is perfect for cafés, bars, restaurants and larger outdoor areas, offering the widest coverage of heat in the market.



  • The most efficient Infrared: Short-wave’s 92% radiant efficiency means you feel warmth even in windy conditions because heat does not drift away on the breeze.
  • Market leading heat coverage: Patented heat projection provides wider coverage – only 2000W heats up to 20m².
  • Instant heat – full power within 1 second of switch on means no wasted energy pre-heating.
  • Long life – InFraCaLoR® halogen lamps have up to 7000 hours of life, meaning low maintenance costs.
  • Warm gold halogen lamp – gives 80% reduction in light output compared to traditional infrared lamps, offering the ambience of an open fire.
  • Designed for outdoor use: fully weatherproof so can be operated safely in all weathers. IPX5 certified.



Contact Us HERE or call 08 7122 1114 to take advantage of our complimentary design service. Our expert team will customise an efficient layout plan to fit your space/project.

Want to know more? Visit Frequently Asked Questions





The Heliosa 66 infrared heater is a stylish heater which will complement the look and feel of any outdoor area. Its large patented parabolic reflector means that its heat output offers a real ‘wow’ factor, while giving its owner the satisfaction of knowing that energy bills are being kept well under control. The Heliosa 66 infrared heater projects heat to 3.5m distance and 5m width when mounted 3m above the ground.

Unlike our Heliosa 44 infrared heater, it will not heat directly underneath the heater from an angled mounting, and this can be advantageous where there are plants or passageways next to your wall. The heater casing is in powder-coated aluminium, finished in glossy Carrara White or textured Cast Iron Grey.

The Heliosa 66 infrared heater includes a tilt-and-swivel bracket for mounting on a wall or hook bracket. For ceiling and under-the-eaves installation, a separate 150mm extension long wall bracket is required. The heater comes with a stainless-steel protective grill which is optional but we recommend that it be fitted before installation – this is simple to do.

Every single heater has a 3m lead but no plug so that it can be wired into an electrical circuit. If you wish to have a plug attached prior to shipment, you need to make a note in the ‘Comments’ section at checkout – we can do this at no extra cost to you.





  • Rec. mounting height: 2.4 – 2.7m.
  • Rec. mounting angle: 30° – 45° from horizontal.
  • Throw: 3.5m.
  • Spread: 5.0m.
  • Distance between heaters: 2.2 – 2.6m.
  • Enclosure: Aluminium casting, powder-coated with aluminium reflector.
  • Colour: White (RAL9016) or Cast Iron grey (RAL7015).
  • Electrical supply: 220-240V ac 50/60 Hz single phase.
  • Power consumption: 2.0kW per hour when on. Insulation: Class 1.
  • Environmental protection: IPx5 (operates with water spray from any direction).
  • Element life: Up to 7000 hours (nominal).
  • Dimensions: 45.5 x 14 x 15.7cm (whd).
  • Weight: 2.1kg.
  • Cable: 3m
  • Other: Tilt & swivel wall bracket. Stainless steel safety grille.
